Transparent From 3.91 to 7.82 Pixel 6500 Nit Manufacture Cheaper LED Display HD and High Brightness HDMI
Transparent from 3.91 to 7.82 pixel 6500 nit manufacture cheaper LED display HD and high brightness HDMISpecification:ItemsParameter PixelPixel pitch: 3.91mm-7.82mmColorChipWaveBrightnessPackingRKinglight620-625nm600mcdSMD1921GKinglight520+/-2.5nm1300mcdSMD1921BKinglight470+/-2.5nm180mcdSMD1921Modu......
Send Inquiry
Product Description
Transparent from 3.91 to 7.82 pixel 6500 nit manufacture cheaper LED display HD and high brightness HDMI
Specification:
Quality Guarantee
Warranty time is 2 years, during this period; we will maintain and replace the defect components for free, if the damage is caused by fault operation, you need to pay for cost. After warrant time is over, we will offer you component parts at our bottom cost.
Technical Support
We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory. All operation manual, software, test reports are available. Any associated CAD drawing on how to fix up the display and some other expert suggestion will be provided. If need, we can send our engineer to your side for instruction, and clients should pay the cost about engineer's trip.
Free Training
You can send your engineers to our factory for one week free of charge training, such as: soft operation, installation, adjustment, basic repairing and so on.
Specification:
| Items | Parameter | ||||
Pixel | Pixel pitch: 3.91mm-7.82mm | ||||
| Color | Chip | Wave | Brightness | Packing | |
| R | Kinglight | 620-625nm | 600mcd | SMD1921 | |
| G | Kinglight | 520+/-2.5nm | 1300mcd | SMD1921 | |
| B | Kinglight | 470+/-2.5nm | 180mcd | SMD1921 | |
| Module | Resolution | 64 x 64 dots | |||
| Size | 250 x 250mm | ||||
| Cabinet | Resolution | 128 x128dots | |||
| Size | 500mmx1000mm | ||||
| Density | 16,384dots/m2 | ||||
| Module Quantity | 2(w) x 4(h)=8pcs | ||||
| Material | Aluminum | ||||
| Weight | 12KG | ||||
| Quantity | 200pcs | ||||
| Whole Screen | Led Screen Size | 100M2 | |||
| Ave. Consumption | 200 W/M2 | ||||
| Max. Consumption | 600 W/M2 | ||||
| Brightness | More than 4000cd/M2 | ||||
| Grey scale | 4096 | ||||
| View Distance | 3-70M | ||||
| Transparency | 70% | ||||
| View Angle | Horizontal: 120°, Vertical: 120° | ||||
| Power Supply | AC 110V/220V+ -10% | ||||
| Drive Mode | 1/16 Scan | ||||
| Refresh Rate | 1920 Hz | ||||
| Control System | Novastar or Colorlight | ||||
| Tolerance between modules | ≤0.5mm | ||||
| Storage Temperature | - 30ºC ~ + 70ºC | ||||
| Working Temperature | - 20ºC ~ + 50ºC | ||||
| Signal Interface | DVI | ||||
| MTBF | ≥10,000 hours | ||||
| Life span | ≥100,000 hours | ||||
| Operation Humidity | 10% ~ 95% | ||||
| Waterproof Grade | IP43 | ||||
| Input source | DVI, S-video, RGB, VGA and etc | ||||
| Operation System | Windows98, 2000, XP, Win7, Win8, Win10 | ||||
Quality Guarantee
Warranty time is 2 years, during this period; we will maintain and replace the defect components for free, if the damage is caused by fault operation, you need to pay for cost. After warrant time is over, we will offer you component parts at our bottom cost.
Technical Support
We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory. All operation manual, software, test reports are available. Any associated CAD drawing on how to fix up the display and some other expert suggestion will be provided. If need, we can send our engineer to your side for instruction, and clients should pay the cost about engineer's trip.
Free Training
You can send your engineers to our factory for one week free of charge training, such as: soft operation, installation, adjustment, basic repairing and so on.
