Outdoor P10 DIP346 Lamp Full Color LED Display Panel

Product Description

Outdoor Super Brightness P10 DIP346 lamp Full Color LED Display panel

Product descripition:

Technical Specifications
NO	Product name	outdoor P10 led display
1	Pixel Pitch(mm)	10mm
2	Pixel configuration	1R1G1B/ DIP 346
3	Pixel density	10000dots/m2
4	Brightness	7500cd/m2
5	Module size(W*H)	160*160mm
6	Module Resolution (W*H)	16 dots x 16dots
7	Module weight	450g
8	Cabinet size (W*H)	960mm×960mm
9	Drive IC	MBI5124
10	Drive mode	1/4scan
11	Viewing Angle(V/H)	110ºC
12	Grey Scale	65536 degree
13	Life time	>100,000 Hours (50%)
14	MTBF	>50,000 Hours
15	Operating Voltage	AC110V/220V±10%
17	Screen Power Consumption	Max: 680w/m2; Average:220w/m2
18	Input Power Frequency	50/60Hz
19	Operating temperature	-30--60ºC
20	Humidity	10%-95%
21	Refresh Rate	≥1200HZ
22	Control Method	Synchronized with computer monitor

Outdoor P10 DIP346 Lamp Full Color LED Display Panel

FAQ :
1. Q: Can I get some samples?
A: Yes,sample order is available for quality check and market test.
2. Q: What's the delivery time?
A: Usually below 100pcs is 3 days quick delivery.
3. Q: How long is the warranty period ?
A: Non-artificial damage, one years warranty
4. Q: Do you have the products in stock?
A: Yes ,of course
5. Q: Freight Cost?
A: The shipping cost depends on different weight;
We will choose the cheapest and safest way according your detail quantities.
6. Q: How does your factory do regarding the quality control?
A: Quality is priority. Every product will be fully assembled and carefully tested before packing and shipping.
