High Brightness P8 Outdoor RGB LED Panel Display

Product Description

P8 SMD Full Color Outdoor LED Panel Display

Description:

1. High Brightness even under sunlight ,Light Weight by using die-casting Aulminum Cbinet

2.Good waterproof IP65 for front and IP54 for rear,anti-corrosion,antifogging,long life span>100000Hours

3. High brightness up to 6800CD, Long view distance from 100M away
4.Made with high quality Epistar leds keep high quality, low lighting decay, energy saving

5. Brightness can be adjusted automatically according to different surrondings,can be set to open and close the screen on fixed automatically

6. Can be fixed on the wall, on the street, on top of building,or be hung for rental to meet the request of live broadcast, live meeting, banquet, party, etc, to display the content what you want, by video, graphics, antimation etc, connect with PC computer or network, also can remoto control with synchronous system.

7.Cabinet size and materials can be customized according different projects

LED Display Specification

The specifications of modules

Items			Parameter
Product Model			P8 Full Color Led Module
Module size			256mm*128mm
Pixel pitch			8mm
Pixel density			15625dots/m2
Pixel configuration			1R1G1B
Module resolution			32dots(W)*16dots
Module maximum power consumption			20W
Module Weight			0.36kg
Driving method			Constant Current Driving
Scanning method			1/4 scan
Interface			HUB75
Brightness			≥6500cd/m2
The specifications of cabinets

Cabinet size			1024mm*768mm
Module quantity			24pcs
Power supply			5V/40A 5V/60A
Cabinet resolution			128*96dots
Optimal viewing distance			86M~100M
Optimal viewing angle			160°(W) 120°(H)
RHWorking temperature			(Work :-25°C~+50°C)
System operating humility			10%-95%
The specifications of power supplier

Operating Voltage			AC220V±10%
Average power consumption			350W/H
Maximum power consumption			≤760W/m2
Electric current			≤20mA(single LED)
The specifications of control card
Control Panels			Pentium4 or above
Operating system			WIN98/2000/NT/XP
Control model			Synchronization with PC
The specifications of the main technical parameters

Driving device			Constant Current Driving
Refresh rate			≥1000HZ
Grey scale			RGB Each 256, can display 16.7M colors)
MTBF			≥9000hours
Power switch			Automatic Switch
Display Mode			800600/1024768/1280*900

Our service

1. Your inquiry related to our products or price will be replied in 24hrs

2. OEM&ODM, any your customized lightings we can help you to design and put into product

3. Distributorship are offered for your unique design and some our current models

4. Protection of your sales area, ideas of design and all your private information

5. Top quality+Reasonable price+Responsible After Service=Successful & Win

6. Jiacai can offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and led large screen full color display.

Trade Terms

1. Package: Anti-shaking wooden package, Air flight case or Carton package

2. Payment: T/T, 40% deposits before production, 60% balance to be paid before delivery

3. Shipping freight are quoted under your requests

4. Shipping port: Xiamen, China

5. Warranty time: 2 years

6. Delivery time: 3-15 working days
