China Energy Saving Outdoor High Brightness Full Color P3 LED Display Panel for Advertising Screen

Product Description

Energy saving Outdoor High Brightness Full Color P3 LED Display Panel for Advertising Screen

Features

*The co-negative technology is used to effectively control the temperature rise, the temperature is reduced by 60% compared with the conventional screen, and the display screen is more stable.

*2.8V/3.8V dual-channel power supply technology is used to save half of the power supply and effectively reduce the failure rate, and the cold light source is high brightness to better meet the high reliability requirements of outdoor applications.

*Low power consumption, power saving about 70%, using energy-saving drive IC, to reduce drive circuit loss and reduce operating costs;

*low heat, natural heat dissipation without air conditioning, zero working noise;

*CNC finishing magnesium-aluminum box, lighter than traditional iron box 22KG/ square meter, lighter than die-cast aluminum box 8KG/ square meter;

*fully sealed magnesium-aluminum box design, waterproof, dustproof, anticorrosion, flame retardant, UV resistance, protection grade as high as IP65;

Energy Saving Outdoor High Brightness Full Color P3 LED Display Panel for Advertising Screen

Specifications:

Module Specification
1	Pixel Pitch	3mm
2	Pixel Configuration	SMD1515
3	Module Resolution	64*64 pixels
4	Module Pixles	4096 pixels
5	Module Size	192*192mm
Cabinet Specification
1	Cabinet Size(W * H)	768*768mm
2	Cabinet Resolution(dot)	256*256
3	Module Quanity (pcs)	16pcs
4	Cabinet Pixels	65536 pixels
5	Pixel Density	111111 pixels/m²
6	Cabinet Materials	Steel Cabinet
7	Cabinet Weight	30kg
8	Packaging	Wooden case
Whole Screen Specification
1	Screen Brightness	3000-3300cd/m²
2	Driving Method	1/16 scan
3	Best Viewing Distance	3m - 30m
4	Max. Power Consumption	700W/m²
5	Average Power Consumption	300W/m²
8	Frame Frequency	≥60Hz
9	Refresh Frequency	≥1920Hz
10	Uninterrupted Working Hours	≥72 hours
11	Screen Life-span	≥100,000 hours
12	MTBF	≥5,000 hours
13	Discrete Blind Spot Rate	<1/10000
14	Continuous Blind Spot Rate	None
15	Blind Spot Rate	<1/10000
16	Protective Scale	For indoor use only
17	Screen Plainness	<±1mm
18	Power Supply Mode	AC220±10% 50Hz/AC110±10% 60Hz
19	Environment Temperature & Humidity	Temperature:-20 Celsius~+60 Celsius
		Humidity:10%~90% RH
20	Control Mode	Synchronous display with control PC by DVI
21	Control System	Linsn, Nova-star, Colorlight or as you required
22	Display Content	Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc.
23	Interface	Standard Ethernet
24	Transmission Distance	Multi mode fiber <500m, single mode fiber <30km,internet cable <100m
25	Certificate	CE, RoHS, FCC

Applications:

Business Organizations	super market, shopping mall, office building, industrial park, exclusive agency, chain shop, hotel, restaurant, travel agency, pharmacy, etc.
Financial Organizations	banks, security company, insurance company, post office, hospital, school, etc.
Public Places	subway, airport, train/bus station, gas station, toll station, bookstore, park, exhibition hall, stadium, museum, convention center, ticket center, HR market, lottery center, plaza, commercial building, parking lot, etc.
Entertainments	movie theater, fitness hall, country club, night club, massage room, bar, cafe, Internet bar, beauty shop, golf course, casino, etc.

Our services:

1.Your inquiry about our products or the price will be replied within 24 hours!
2.We provide 2 years for warranty and lifelong maintaining, you will appreciate our warm after-sale service.
3.We will delivery goods as you demand ,you can choose the cheaper and more convenient way!

Trade Terms:

1.Packing: Anti-shaking wooden cabinet /Air flight case/carton
2.Shipping port: Shenzhen. China
3.Shipping freights are quoted according to your requests
4.Delivery time:20 working days
5.Two years warranty, lifelong maintaining. In the Maintenance period, free of all maintenance charges.
After Maintenance period, only charge the material cost fees.
