P5 Indoor Performance LED Display Panel
  • P5 Indoor Performance LED Display PanelP5 Indoor Performance LED Display Panel

P5 Indoor Performance LED Display Panel

1. UL, CE&RoHS certificate2. Excellent visual effect3. Low power consumption4. Life Span: 100, 000hrs5. Warranty 5yearFeatures and Advantages1. In order to ensure that images and tests are clear&c......

Send Inquiry

Product Description

1. UL, CE&RoHS certificate
2. Excellent visual effect
3. Low power consumption
4. Life Span: 100, 000hrs
5. Warranty 5year
Features and Advantages

1. In order to ensure that images and tests are clear, vivid and consistent, all the chips for the entire RGB LED screens for outdoor screens within 100 square meters are at the same grade such as the same brightness and the same wavelength.

2. In order ensure screen background can become matt, completely absorb LED reflective light and eliminate shadow and ghosting, we adopt imported glue to varnish module surface, the glue thickness for each module is not more than 0.1mm, so the color is consistent and uniform.

3. To ensure product reliability and long life, we select the best chips for all outdoor display, red chips are from Hitachi brand, blue and green ones come from US CREE.

4. Easy to maintain and achieve single-pixel and single-lamp maintenance.

5. High quality at competitive prices.

6. Wide applied in stadiums, advertisemjent, banks, securities exchange, stations, entertainment, shopping malls, postal offices, schools, monitoring, restaurants, enterprises etc

The technology parameter  of P5 indoor

ItemP5
1Pixel pitch5mm
2Size of unit board320*160mm
3Resolution of unit board64X 32
4Density of pixel40000dots/m2
5Pixel configuration1R1G1B
6Red wavelength625±2nm
7Green wavelength525±2nm
8Blue wavelength470±2nm
9Colors16777216
10Best viewing distance≥5m
11Horizontal viewing angle140°
12Maximum power consumption600~1000W/m 2
13Brightness2000-5000cd /m 2
14Gray scale16bits per color
15Color temperature6500k
16Control methodSynchronization & Asynchronization
17Driving method1/16 or 1/8 scanning
18Frame frequency60Hz
19Refresh frequency350Hz
20Working voltageAC220V/110V±10%
21IP gradeIP20~IP65
22Working temperature-20°C~80°C
23MTBF>10000 hours
24Life span>100,000 hours
25Computer operation system Win XP/Vista/ Win 2000/WIN7ect.
26Video signalRF, S-Video, RGB, RGBHV, YUV, YC.ect
